2026 Chevrolet Express Cargo 3500 Extended Wheelbase (WT, RWD)
Van TrucksCommercial Vans
Description
Chevrolet Express Cargo 3500 Extended Wheelbase (WT, RWD)
Specifications
Manufacturer
Chevrolet
Model
Express Cargo 3500 Extended Wheelbase (WT, RWD)
Year
2026
Category
Van Trucks
Subcategory
Commercial Vans
Front Head Room
40.85 in
Front Leg Room
41.35 in
Front Shoulder Room
68.85 in
Front Hip Room
65.47 in
Wheelbase
155.00 in
Length, Overall
244.05 in
Width, Max w/o mirrors
79.25 in
Height, Overall
84.25 in
Overhang, Front
39.70 in
Ground to Top of Load Floor
29.75 in
Ground Clearance, Front
9.65 in
Ground Clearance, Rear
8.60 in
Rear Door Opening Height
47.95 in
Rear Door Opening Width
53.42 in
Step Up Height - Front
27.44 in
Step Up Height - Side
27.90 in
Cargo Area Length @ Floor to Console
173.65 in
Cargo Area Length @ Floor to Seat 1
146.75 in
Cargo Box Width @ Wheelhousings
52.47 in
Cargo Box (Area) Height
55.08 in
Cargo Volume
283.60 ft³
Passenger Capacity
2
Gross Axle Wt Rating - Front
4,300 lbs
Gross Axle Wt Rating - Rear
6,084 lbs
Curb Weight - Front
3,001 lbs
Curb Weight - Rear
2,328 lbs
Reserve Axle Capacity - Front
1,246 lbs
Reserve Axle Capacity - Rear
3,374 lbs
As Spec'd Curb Weight
5,414 lbs
As Spec'd Payload
4,186 lbs
Gross Combined Wt Rating
15,000 lbs
Maximum Payload Capacity
4,271 lbs
Trim Curb Weight
5,414 lbs
Standard Weight - Front
53 lbs
Standard Weight - Rear
32 lbs
Base Trim Weight - Front
3,054 lbs
Base Trim Weight - Rear
2,360 lbs
Gross Vehicle Weight Rating
9,600 lbs
Gross Axle Weight Rating
10,384 lbs
Curb Weight
5,329 lbs
Reserve Axle Capacity
4,620 lbs
