2025 Chevrolet Express Cargo 2500 Extended Wheelbase (WT, RWD)
Van TrucksCommercial Vans
Description
Chevrolet Express Cargo 2500 Extended Wheelbase (WT, RWD)
Specifications
Manufacturer
Chevrolet
Model
Express Cargo 2500 Extended Wheelbase (WT, RWD)
Year
2025
Category
Van Trucks
Subcategory
Commercial Vans
Front Head Room
40.85 in
Front Leg Room
41.35 in
Front Shoulder Room
68.85 in
Front Hip Room
65.47 in
Wheelbase
155.00 in
Length, Overall
244.05 in
Width, Max w/o mirrors
79.25 in
Height, Overall
84.25 in
Overhang, Front
39.70 in
Ground to Top of Load Floor
29.75 in
Ground Clearance, Front
9.65 in
Ground Clearance, Rear
8.60 in
Rear Door Opening Height
47.95 in
Rear Door Opening Width
53.42 in
Step Up Height - Front
27.44 in
Step Up Height - Side
27.90 in
Cargo Area Length @ Floor to Console
173.65 in
Cargo Area Length @ Floor to Seat 1
146.75 in
Cargo Box Width @ Wheelhousings
52.47 in
Cargo Box (Area) Height
55.08 in
Cargo Volume
283.60 ft³
Passenger Capacity
2
Gross Axle Wt Rating - Front
4,300 lbs
Gross Axle Wt Rating - Rear
5,360 lbs
Curb Weight - Front
2,971 lbs
Curb Weight - Rear
2,354 lbs
Reserve Axle Capacity - Front
1,276 lbs
Reserve Axle Capacity - Rear
2,624 lbs
As Spec'd Curb Weight
5,410 lbs
As Spec'd Payload
3,190 lbs
Gross Combined Wt Rating
15,000 lbs
Maximum Payload Capacity
3,275 lbs
Trim Curb Weight
5,410 lbs
Standard Weight - Front
53 lbs
Standard Weight - Rear
32 lbs
Base Trim Weight - Front
3,024 lbs
Base Trim Weight - Rear
2,386 lbs
Gross Vehicle Weight Rating
8,600 lbs
Gross Axle Weight Rating
9,660 lbs
Curb Weight
5,325 lbs
Reserve Axle Capacity
3,900 lbs
